Power connection, ESD air: 15KV, surge: 4KV
#MODBUS SERVER TCP SERIAL SERIAL#
Can be used as a repeater for two serial device communications directly, e.g.: PLC to PLC ġ8.Support firmware upgrade through TTL, firmware update is more convenient ġ9.Small in size, 96mm*68mm*25mm, and supports wall mounting and DIN 35mm rail mounting. Support automatically connect and reconnect the server after disconnection ġ6.Support serial port strategy function, data path can be program, for example: RS232 and RS485 bi-direction communication (RS232 ⇄ RS485), RS232 and server 1 bi-direction communication (RS232 ⇄ server 1) ġ7. Supports programmable ”Handshake” and heartbeat package function, which can facilitate ID identification and data communication of the device on the cloud platform ġ5. Supports up to 5 TCP/UDP Clients and 5 TCP/UDP Servers connections simultaneously ġ4. Support server domain name or IP address ġ1.Built-in TCP/IP protocol stack, support transparent transmission and Modbus RTU to Modbus TCP Protocol ġ2.Supports multiple working modes:TCP Server, TCP Client, UDP Server, and UDP Client ġ3. Support custom device names for easy user identification ġ0. Support static IP address or DHCP to obtain IP address automatically, and query the devices in the network through UDP broadcast protocol ĩ.
#MODBUS SERVER TCP SERIAL SOFTWARE#
Metal shell, protection class IP30, suitable for industrial control applications ħ.The configuration software supports WIN XP, WIN 7, WIN 8 and WIN 10, friendly interface Ĩ.
Built-in industrial grade ARM® CortexTM core, high performance, stable and reliable ģ.Support 1 channel RS-232, 1 channel RS-485 and 1 channel TTL Ĥ.Serial port baud rate supports 4800bps-128000 bps,supports None, Odd, Even check mode ĥ.Supports 1 channel RJ45 Ethernet port, with link and data indicator, built-in isolation transformer, up to 2KV electromagnetic isolation Ħ. It is the most popular industrial internet of things (IIOT) gateway.ġ.Wide working voltage, support 9-36V DC power supply, interface is DC Q2.1 jack and terminal block, and with anti-reverse protection design Ģ. The D224 Serial Device Server provides a simple and cost-effective way to bring the advantage of remote management and data accessibility to thousand of devices that can not connect to a network. It accepts upto 5 connections to communicate at the same time, no matter the Serial Devcie Server be used as Server or Client. It not only allows an Ethernet master to control serial slaves, but also allow serial masters to control Ethernet slaves. The D224 Serial Device Server provide a feature that can allow users to select master or slave operation mode for each serial port. The D224 Serial Device Server provides is a useful device to convert RS485/232/TTL data to TCP/IP network, it also can be used as converting Modbus RTU to Modbus TCP, and performs as a serial port converter to create the communication from RS485 to RS232 or TTL, moreover, it can be used as a repeater for two serial device communication directly, e.g.: PLC to PLC.
